Product Summary

The N82S100 is a bipolar field programmable logic array. Its applications include CRT display systems, random logic, code conversion, function generators, look-up and decision tables, microprogramming, address mapping, character generators, fault detectors.

Parametrics

N82S100 absolute maximum ratings: (1)supply voltage: 7V; (2)input voltage: 5.5V; (3)output voltage: 5.5V; (4)input current: 30mA; (5)temperature range: 0 to 75℃; (6)storage temeprature: -65 to 150℃.

Diagrams

N82S100 block diagram
