Product Summary

The 82S137 is a bipolar prom. It is field programmable, which means that custom patterns are immediately available by following the fusing procedure given in this data manual.

Parametrics

82S137 absolute maximum ratings: (1)supply voltage: 7Vdc; (2)input voltage: 5.5V; (3)output voltage: 5.5V; (4)temperature range: 0 to 75℃; (5)storage temperature: -65 to 150℃.

Features

82S137 features: (1)power dissipation: 0.13mW/bit typ; (2)on-chip address decoding; (3)no separate fusing pins; (4)fully TTL compatible; (5)unprogrammed outputs are low level.

Diagrams

82S137 block diagram
